Solenoid controlled 3/2×1, R3/8", 3x press.contr.valve+T
Product code: E32x1PVD-24V
VAT 0%
Price: €327.60
€480.00
Suitable for articuladet blows
When unpowered, both cylinders operate diaconal and
current on the right cylinder (connections B1 and B2)
When unpowered, both cylinders operate diaconal and
current on the right cylinder (connections B1 and B2)
Solenoid controlled 3/2-2 directional valve with a single solenoid
- connection R1/2" and R3/8"
- voltage 24VDC (30W)
- flow 60 l/min
- max.pressure 210 bar
- adjustable shock relief valves 80-220 bar in ports A1 and B1, factory setting 150 bar
- fixed shock relief valve with inlet valve 175 bar in ports A2-/B2
- T connection to tank or pressure accumulator
- connection R1/2" and R3/8"
- voltage 24VDC (30W)
- flow 60 l/min
- max.pressure 210 bar
- adjustable shock relief valves 80-220 bar in ports A1 and B1, factory setting 150 bar
- fixed shock relief valve with inlet valve 175 bar in ports A2-/B2
- T connection to tank or pressure accumulator
