Solenoid controlled 3/2×1, R3/8", 3x press.contr.valve+T

Solenoid controlled 3/2×1, R3/8", 3x press.contr.valve+T

Product code: E32x1PVU-12V

VAT 0%

€327.60

€480.00

Suitable, for example, for a wing snow bucket

- when de-energized, the right cylinder (connections B1 and B2) moves
- when energized, both cylinders move in parallel (no flow distribution, ie the easier cylinder moves first)
Solenoid controlled 3/2-2 directional valve with a single solenoid

- connection R1/2" and R3/8"
- voltage 12VDC (30W)
- flow 60 l/min
- max.pressure 210 bar
- adjustable shock relief valves 80-220 bar in ports A1 and B1, factory setting 150 bar
- fixed shock relief valve with inlet valve 175 bar in ports A2-/B2
- T connection to tank or pressure accumulator
