Solenoid controlled 3/2×2, R3/8", 3x press.contr.valve+T
Product code: E32x2PVU-12V
VAT 0%
Price: €354.90
€520.00
Suitable, for example, for a wing snow bucket
- when de-energized, the right cylinder (connections B1 and B2) moves
- current in B-coil, both cylinders connected in parallel (no flow distribution, ie the easier cylinder moves first)
- current in both coils, the left cylinder (connections A1 and A2) moves
- when de-energized, the right cylinder (connections B1 and B2) moves
- current in B-coil, both cylinders connected in parallel (no flow distribution, ie the easier cylinder moves first)
- current in both coils, the left cylinder (connections A1 and A2) moves
Solenoid controlled 3/2-2 directional valve with two solenoids
- connection R1/2" and R3/8"
- voltage 12VDC (30W)
- flow 60 l/min
- max pressure 210 bar
- adjustable shock relief valves 80-220 bar in ports A1 and B1, factory setting 150 bar
- fixed shock relief valve with inlet valve 175 bar in port A2/B2
- T connection to tank or pressure accumulator
- connection R1/2" and R3/8"
- voltage 12VDC (30W)
- flow 60 l/min
- max pressure 210 bar
- adjustable shock relief valves 80-220 bar in ports A1 and B1, factory setting 150 bar
- fixed shock relief valve with inlet valve 175 bar in port A2/B2
- T connection to tank or pressure accumulator
