Solenoid cont. 8/3 directional cont. valve R3/8" pres.control
Product code: E8312P4-12V
VAT 0%
€604.50
€930.00
Suitable for U-plow use, for example
When turned off, the reversal works diaconal
When powered, the wings each operate separately, simultaneous use of the wings is not possible
When turned off, the reversal works diaconal
When powered, the wings each operate separately, simultaneous use of the wings is not possible
Solenoid controlled 8/3 directional valve
- connection R1/2"
- voltage 12VDC (36W)
- flow 75 l/min
- max. pressure 210 bar
- adjustable shock relief valves in ports C1 and C3
- adjustable shock relief valves with inlet valves in ports
C5 and C6
- fixed shock relief valves with inlet valves in ports C2 and C4
- Tank/pressure accumulator connection T
- connection R1/2"
- voltage 12VDC (36W)
- flow 75 l/min
- max. pressure 210 bar
- adjustable shock relief valves in ports C1 and C3
- adjustable shock relief valves with inlet valves in ports
C5 and C6
- fixed shock relief valves with inlet valves in ports C2 and C4
- Tank/pressure accumulator connection T
