Solenoid controlled 8/3 directional control valve R1/2

Suitable for use with zoom plough ang a wing snow bucket, for example

Second wing C1 and C4 are de-energized (half selectable by connection)
The other electricity works by shrinking and spreading both wings simultaneously (no flow distribution)
With the second electricity, the second wing C2 and C3

Note! In the contraction / spreading position, when the wing hits an obstacle, the other wing can also move

Solenoid controlled 8/3 directional valve

- connection R1/2"
- voltage 24VDC (36W)
- flow 75 l/min
- max. pressure 210 bar
- adjustable shock relief valves 80-220 bar in ports C1 and C3, factory setting 150 bar
- inlet valves in ports C2 and C4
- tank/pressure accumulator connection T
